WHY200: the game changer debut at Cannes Yachting Festival
by Wally Yachts 11 Sep 2021 23:29 PDT
previous next - 1
- 2
- 3
- 4
- 5
- 6
- 7
Wally's first full-wide-body model once again pushes design boundaries.
With its wide body design, this 200 GT yacht offers far larger volumes compared to traditional motorboats, plus a living space and stability that are definitely the greatest of the market segment. It essentially provides all the advantages of a catamaran but has none of its limitations.
The innovative motor yacht combines the comfort and space of a much larger displacement yacht with the speed and performance of a semi-displacement boat. Measuring less than 24m loadline, the yacht is rewriting the rules to make volume the most important gauge of a yacht. The project was developed by Wally's design team headed by Luca Bassani and the Ferretti Group Engineering Department, who worked with Laurent Giles NA Ltd for the naval architecture and Studio A. Vallicelli & Co for interior design.
The 'Wow Bow'
In keeping with a design philosophy that aims to combine form and function with new and immersive yachting experiences, the WHY200 features a spectacular 4.7-metre high glazed bow to maximise seaworthiness like working explorer vessels. This houses a stunning 37sqm master suite that commands the sea with an uninterrupted 270-degree view of the horizon. The eye-catching upper deck has a futuristic glass-and-carbon dome and an extended, structural top with no supporting pillars.
Room to entertain
A spectacular one-piece laminated carbon staircase connects the three decks and makes bulkheads superfluous in the huge 50sqm open living area. On deck, the fold-down beach club bulwarks give access to the sea on three sides and expand the living area to 32sqm. In addition, WHY200 boasts two garages with a storage capacity never seen before on yachts of this size, able to accommodate a 4.15m jet tender, wave runner, Seabob, paddleboard and all manner of water toys. Positioned on either side, the garages permit a large walkway instead of the classic two narrow ones resulting from a garage to one side.
Speed and stability
The hull has been specifically developed for this semi-displacement yacht and tank tested to optimise efficiency while cutting through the waves with no slamming and minimal pitching, like all Wally hulls. The first unit is powered by four Volvo Penta D-13 IPS 1350 engines of 1000hp each, enabling the WHY200 to cruise at up to 23 knots while maintaining perfect horizontal trim and guest comfort on board. The wide beam combined with the zero-speed fin stabilisers and optional twin Seakeeper gyros ensure stability under way and at anchor.
WHY200 - Main technical specifications
Main sizes:
- Length overall: 27.03 m – 88’ 8”
- Load line length: 23.98 m - 78’8"
- Beam max: 7.66 m - 25’2”
- Draught (half load): 2.0 m - 6’ 5”
- Displacement (half load): 118 tons
- Tonnage: 199 GRT
Engines:
- STD: 4 x Volvo Penta D13 IPS1200 900 mhp / 588 kW
- Max Speed 21 knots*
- Cruise Range 390 nm at 18 knots*
- OPT: 4 x VOLVO PENTA D13 IPS1350 power 1000mhp / 735 kW @ 2400 rpm
- Max Speed 23 knots*
- Cruise Range 370 nm at 20 knots*
- STD/OPT Long Range Cruise 1000nm at 10 knots*
(Long range cruise can be achieved with 4 x engines at 1100RPM or 2 x engines** at 1500RPM)
**requires trailing pumps OPT installation
Design: Wally / Ferretti Group
Naval architecture: Laurent Giles NA
Interior Design: A. Vallicelli & C.
Accommodation:
- STD: 8 guests in 4 cabins
- OPT: 10-12 guests in 5 cabins
- Crew: 5 members in 3 cabins; crew mess
- Maximum number of people onboard: 20
Fuel tanks: 12.000 litres - 3,170 US gal
Fresh water: 2.200 litres - 581 US gal
Design Category Directive 2013/53/EU CE: Cat A
Water toys: two garages for up to 4.05m tender/waverunner
Standard hydraulic folding bulwarks
Standard Transformer platform
Performance:
* The performance is estimated in the following conditions:
Standard version displacement of the yacht: 114 ton at 1/3 load, clean hull, 25C air temperature, good weather conditions, four persons onboard.
Overloading the yacht by: two tons, results in top speed decrease of 1 kn
