ISA Yachts, a brand of Palumbo Superyachts, presents the new Sportivo line which includes the 100, 120 and 140 models.

The design aims at a dominating combination of sporty lines typical of the coupé automotive world and interiors characterized by large volumes and an extremely contemporary imprint. ISA Sportivo 100 will be the first model to be officially presented in 2025.

Designed by the effervescent creativity of Enrico Gobbi - Team for Design, with naval engineering by Palumbo Superyachts, ISA Sportivo 140 is the flagship of a line identified by extremely high-quality construction.

ISA Sportivo 140 has large external spaces and a fairly restrained superstructure. A highly innovative element is the military windshield designed to push the superstructure further, generating a long bonnet like a large sports coupé car.

Definitely a boat with a sporty look and futuristic details that combines a clean design with sophisticated modern furnishings with a Mediterranean flair.

Standing at the stern, we immediately notice an open cockpit thanks to three large terraces that slope towards the sea and where, starting from the top, are respectively placed: the living area with sofa, chairs and a sizeable sunbathing area, the swimming pool with relaxation bench overlooking the sea and natural-stone effect passageway, and finally the platform under the sun.

The bow hides a proper relaxation area with fireplace and Jacuzzi which can be alternatively transformed into a cinema room.

The upper deck has been stretched to its maximum to fit naturally into the sleek line of this model. Certainly, one of the largest in its category to ensure maximum livability and versatility, it includes a dining area for 10 people, a spacious living area with sofa, bar and a second relaxation area, very panoramic, positioned at the very bow end.

The interiors are rich in leather, lacquered wood and metal panels, all combined with a different pop of color for each area.

The main salon opens onto the bar and then gives way to the sofas and dining area. The large fully opening floor/ceiling windows combined with the balcony, which can also be opened on the port side, provide an exceptionally enjoyable sea view.

The owner suite is located amidships to optimize the maximum beam of almost 9 metres and includes a walk-in closet with vanity, double bathroom with large central shower, sofa on the port side and opposite lounge area fitted with floor/ceiling windows combined with large opening terrace.

Hull and superstructure will be in GRP and carbon fiber.
Two 3440 kW MTUs will push the boat to a maximum speed of 32 knots and guarantee a cruising speed of 26 knots.

Three double cabins plus the captain's cabin will accommodate the 7 members of crew. The tender is housed in the garage located on the port side.

ISA Sportivo 120 adopts the philosophy of the flagship and can equally accommodate up to 8 people into 4 comfortable cabins with private bathrooms. It is endowed with a Jacuzzi in the bow and a sizeable and versatile sun deck. It mounts 3xMTU engines of 1939 kW each and can reach a maximum speed of 36 knots. The cruising speed is 230 knots while at 12 knots it guarantees a range of 550 nautical miles.

ISA Sportivo 140 Specifications:

  • Model: ISA SuperSportivo 140
  • Type: Motor Yacht
  • Hull: Planing
  • Classification: Rina C Hull
  • Naval architect: Palumbo Superyachts
  • Exterior design: Enrico Gobbi Team for Design
  • Interior design: Enrico Gobbi Team for Design
  • Hull material: fiber reinforced plastic
  • Structure material: fiber reinforced plastic
  • LOA: 43.60 m / 143.5 ft
  • LWL at full load: 36.50 m / 119 ft
  • Moulded beam: 8.69 m / 28.1 ft
  • Draught at full load: 1.52 m / 4 ft
  • Displacement at full load: 240 t
  • Gross tonnage: 298 GT
  • Fuel oil: 31000 lt / 8289.3 gal
  • Fresh water: 5000 lt / 1320.8 gal
  • Black/Grey water: 7540 lt / 1991.8 gal
  • Main engines: 2 x mtu 16v4000m93l
  • Engine power: 2 x 3440 kw @ 2100 rpm
  • Gearboxes: 2 x ZF (gear ratio tbd)
  • Generators: 2 x 125 kw
  • Thruster: a fixed pitch bow thruster, power 55 kw
  • Stabilisers: two pairs of non retractable fins, including zero speed stabilisation
  • Maximum speed: 32.0 knots
  • Cruising speed: 26.0 knots
  • Range at 26 knots: 540 nm
  • Desalination plant: one desalinator - total capacity 8500 lt / day 2245.4 gal / day
  • Passengers / cabins: 8/4
  • Crew / cabins: 3/2

ISA Sportivo 120 Specifications:

  • Model: ISA SuperSportivo 120
  • Type: Motor yacht
  • Hull: Planing
  • Classification: Rina C Hull
  • Naval architect: Palumbo Superyachts
  • Exterior design: Enrico Gobbi Team for Design
  • Interior design: Enrico Gobbi Team for Design
  • Hull material: GRP carbon fiber
  • S/structure material: GRP carbon fiber
  • LOA: 36.45 m / 119 ft
  • LWL at full load: 30.00 m / 98 ft
  • Maximum beam: 7.50 m / 24 ft
  • Draught at full load: 1.52 m / 4 ft
  • Displacement at full load: 173 t
  • Gross tonnage: 235 GT
  • Fuel oil: 22000 lt / 5811.7 gal
  • Fresh water: 4000 lt / 1056.6 gal
  • Black/Grey water: 4600 lt / 1215.1 gal
  • Main engines: 3 x mtu 16V2000M96L
  • Engine power: 3 x 1939 kw@ 2450 rpm
  • Gearboxes: ZF 3060
  • Generators: 2 x 70 kw
  • Thruster: a fixed pitch bow thruster, power 35 kw
  • Stabilisers: one pair of non retractable fins, including zero speed stabilisation
  • Maximum speed (100% mcr): 36 knots (approx)
  • Cruising speed: 30 knots (approx)
  • Range at 12 knots: 550 nm
  • Desalination plant: one desalinator - total capacity 5500 lt / day 1452.9 gal / day
  • Passengers/cabins: 8/4
  • Crew/cabins: 3/2
