Barton Marine Removable Mainsheet Track System
by Mark Jardine 3 Feb 04:00 PST
Removable Mainsheet Track System © Mark Jardine
This adaptable mainsheet track system is designed to span between the cockpit seats when sailing but is easily removable to ensure cockpit space is not compromised when you want to relax on board.
The removable track system is available in two sizes and can be used on yachts up to a maximum of 11.0m (36ft). The track has a maximum unsupported length of up to 700mm (28in). It can be attached and removed in seconds and uses Barton's beam section track.
Fitting Barton Marine's new removable track couldn't be simpler; end plates are bolted either side of the cockpit, on the cockpit wall, the track is then slid under these plates and lifted vertically which automatically lock it in position. To remove the mainsheet track you just push in the locking pin on either side, lower the track and slide it out of the way.
Part Numbers (Available in Silver or Black Anodised Finish)
Silver
- 20910 Size 1 Suitable for yachts up to 8.5m (28.5ft)
- 24910 Size 2 Suitable for yachts up to 11m (36ft)
Black
- 20910B Size 1 Suitable for yachts up to 8.5m (28.5ft)
- 24910B Size 2 Suitable for yachts up to 11m (36ft)
Find out more on the Barton Marine website here.
